Dahua IP dómkamera - IPC-HDBW3541E-AS (AI; 5MP, 2,8mm, kültéri, H265+, IP67, IR 50m; ICR, WDR, PoE, I/O,audio, IK10, SD)

Camera

Image Sensor - 1/2.7”5Megapixel progressive CMOS

Effective Pixels - 2592 (H) ×1944 (V)

ROM- 128 MB

RAM - 512 MB

Scanning System - Progressive

Electronic Shutter Speed - Auto/Manual 1/3 s–1/100000 s

Min. Illumination - 0.005 Lux@F1.6

IR Distance - 50 m (164.0 ft)

IR On/Off Conrol - Auto/Manual

IR LEDs Number - 3 (IR LEDs)

Pan/Tilt/Rotation Range - Horizontal: 0°–355°; vertical: 0°–65°; rotation: 0°–355°



Lens

Lens Type - Fixed focal

Mount Type - M12

Focal Length - 2.8 mm; 3.6 mm; 6 mm

Max. Aperture - F1.6

Field of View -

2.8 mm: Horizontal: 98°; vertical: 72°; diagonal: 130°

3.6 mm: Horizontal: 80°; vertical: 59° ; diagonal: 106°

6 mm: Horizontal: 50°; vertical: 36°; diagonal: 64°

Iris Type - Fixed aperture

Close Focus Distance -

2.8 mm: 0.9 m (3.0 ft)

3.6 mm: 1.6 m (5.3 ft)

6 mm: 3.2 m (10.5 ft)

Perimeter Protection

Tripwire; intrusion (Recognition of human and vehicle)

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression - H.265; H.264; H.264H; H.264B; MJPEG

Smart Codec - Yes

Video Frame Rate -

Main stream (2592 × 1944@1–20 fps)

(2688 × 1520@1–25/30 fps)

sub stream (704 × 576@1–25/30 fps)

third stream (1280 × 720@1–25/30 fps)

Stream Capability - 3 streams

Resolution - 5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control - CBR/VBR

Video Bit Rate -

H.264: 3 Kbps–8192 Kbps

H.265: 3 Kbps–8192 Kbps

Day/Night - Auto(ICR)/Color/B/W

BLC - Yes

HLC - Yes

WDR - 120 dB

White Balance - Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control - Auto/Manual

Noise Reduction - 3D DNR

Motion Detection - OFF/ON (4 areas, rectangular)

Region of Interest(RoI) - Yes (4 areas)

Smart IR - Yes

Image Rotation - 0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution.)

Mirror - Yes

Privacy Masking - 4 areas

Audio

Audio Compression - G.711a; G.711Mu; G726; AAC

Network

Network - RJ-45 (10/100 Base-T)

Protocol - IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;

RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP

Interoperability - ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec

Scene Self-adaptation -Yes

User/Host - 20 (Total bandwidth: 64 M)

Edge Storage - FTP; SFTP; Micro SD Card (support max. 256 G); Dahua Cloud; NAS

Browser -

IE: IE8, IE9, IE11

Chrome

Firefox

Management Software - Smart PSS, DSS, DMSS

Mobile Phone - IOS; Android

Certification

Certifications - CE-LVD: EN60950-1

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

Audio Input - 1-channel (RCA port)

Audio Output - 1-channel (RCA port)

Alarm Input - 1 channel in: 5mA 3V–5V DC

Alarm Output - 1 channel out: 300mA 12V DC

Power

Power Supply - 12V DC/PoE (802.3af)

Power Consumption <7.3W

Environment

Operating Conditions -40°C to +60°C (-40°F to +140°F)/less than≤95%

Strorage Conditions -40°C to +60°C (-40°F to +140°F)

Ingress Protection - IP67; IK10

Structure

Casing - Metal + Plastic

Dimensions - 81 mm × Φ109.9 mm (3.2" × Φ4.3")

Net Weight - 378 g (0.8 lb)

Gross Weight - 523 g (1.2 lb)
